SUPER T-BOLT CLAMP

Gelenkbolzenschellen
Collier à tourillons
Slangklemmen
Abrazadera Super
Collari a bullone
Хомуты

SUPEREX T-BOLT CLAMP

Super T bolt clamp having high band tension is designed for sealing suction and pressure lines.

The clamp with its high strength 8.8 grade T-bolt can be tightened up hard using manual, pneumatic or electrical tools.

Smooth underside and rolled up band edges are gentle on hose and reduce risk of leakage.

The Super clamp contains 3 welding points for increased strength and security, while the specially designed hollow trunnions reduce tensile pressure on the bolt ensuring the customer receive a truly SUPER CLAMP.

Main Applications: agricultural machines, irrigation systems, ship building, mining industry, biogas and chemical industry.

Image module
Quality:
  • W1
  • W2
  • W4
Super T- Bolt Clamp Sizes
Dia Size
(mm)
Band Width
(mm)
Band Thickness Bolt Size
(MxP) * Length (mm)
Quantity / Box
W1 mm INOX mm
17-19 18 0.6 - M5 x 40 200
20-22 200
23-25 200
26-28 200
29-31 20 0.8 0.8 M6 x 50 100
32-35 100
36-39 100
40-43 100
44-47 22 1.2 0.8 M7 x 60 for W1
M6 x 60 for INOX
75
48-51 75
52-55 50
56-59 50
60-63 50
64-67 50
68-73 24 1.5 1.0 M8 x 75 40
74-79 30
80-85 30
86-91 30
92-97 25
98-103 25
104-112 M8 x 85 25
113-121 20
122-130 20
131-139 26 1.5 1.0 M10 x 95 25
140-148 25
149-161 20
162-174 M10 x 105 20
175-187 20
188-200 15
201-213 15
214-226 15
227-239 15
240-252 15
Custom Sizes Available

Technical Drawing:

Image module

Materials:

Materials
Description
Corrosion resistance
in salt spray testing
W1
Mild Steel with Zinc Plating
Min 72 hours
W2
Stainless Steel 430 Band with
Mild Steel Hardware
Min 72 hours
W4
Stainless Steel 304
Min 240 hours

Torques:

Image module
